Leak Chase, a self contained very portable Vacuum Diagnostic system
The Leak Chase is a self contained, very portable Vacuum Diagnostic system offering the latest in Smart Head and miniature dry pumping technology.
This small suitcase sized instrument contains a quadrupole RGA mass spectrometer with all its associated electronics and dry pumping systems.The Leak Chase is available with inlet options including Sniffer Probes and capillary systems. We can customise the...
UHV and HV compatible Titanium and Molybdenum fixings
For research, prototyping, and precision mechanics in-vacuum fixings need to be from durable, heat-resistant material.
Allectra is pleased to offer Titanium (Ti) and Molybdenum (Mo) screws with relative washers and nuts suitable for high and ultra-high vacuum use, for instance for in-vacuum sample mounting, prototype assembly and fixing of critical parts..
Technical background:
A screw’s dimensions are defined with 3 numbers: the...
New Sales and Service engineer in Avactec with experience working with UHV technology at NASA
We are delighted to welcome Jen Skevington as our new Sales and Service engineer in Avactec covering Catalonia and Valencia.
Jen is a mechanical engineer with a background in the automotive industry, along with experience working with UHV technology at NASA.
Avactec is now an agent for MEMS systems from memsstar
Avactec is now an agent for MEMS systems from memsstar
The ORBIS™ range of tools are used for silicon or oxide etch using the technique of vapour phase dry release etching.
MEMS Technology Development
memsstar is a leader in MEMS process technology development, working independently and in conjunction with leading research organizations such as the Fraunhofer Institute, and commercial partners including Millipore...
Manufacture your own vacuum cables
Allectra can offer you the flexibility to manufacture your own in-vacuum cables. We can supply you with the tools to cut, crimp and assemble your own vacuum cables.
They are available among other components:
Ribbon Cable
Strain Relief
HV Conector
HV Housing
Etc.
Alternatively, we can provide ready made cables to your specification, enabling you to use the components immediately without...
Allectra now offers a special series of quick to change O-ring sealed Sub-D feedthroughs on fixed size base plates
For applications down to 10-7 mbar, Allectra offers the Sub-D on a rectangular base plate with Viton O-ring seal.
This product is the perfect solution to incorporate Sub-D feedthroughs onto Aluminium chambers and enables quick exchange if a different configuration is required.
Also available with High Current Sub-D’s and / or coaxial feedthroughs.
You can find more information by click below or...
Avactec can now offer screws, nuts and washers for vacuum applications
Screws, nuts and washers for vacuum applications.
The widest range we offer are made from A2 stainless steel and are precision cleaned for UHV environments. The range is so large that we can’t list everything available, so please contact us for a quotation.
When calculating the price, we need to know:
- The type of thread
- The length of the screw
- The...
Miniature PT100 resistor for UHV use, 343-PT100-C2
Miniature PT100 resistor for UHV
Allectra offers a very small PT 100 resistor for precise temperature measurement between -70°C and +500°C.
The class F0.1 (= 1/3 Class B) resistor offers very low tolerances and a higher stability than thermocouples.
The resistor is offered on its own or with 4 cables connected. Other cable configurations are available on request.
Maximal allowed errors of...
Allectra now offer a special series of Base Plate O-ring sealed Sub-D feedthroughs
For applications down to 10-7mbar, Allectra offers the Sub-D feedthroughs on a rectangular base plate with Viton O-ring seal.
This product is the perfect solution to incorporate Sub-D feedthroughs onto Aluminium chambers and enables quick exchange if a different configuration is required.
Available with High Current Sub-D’s and/or coaxial feedthroughs
UHV Design new Sample Parking Stage
UHV Design have developed a new Sample Parking Stage for flag-style sample plates.
A single carousel stage can hold 4 sample plates and multiple carousel stages can be stacked one on top of each other to give a maximum capacity of 16 sample plates.
The Sample Parking Stage for flag style sample plates commonly used in surface analysis instrumentation, has been designed...
The new Radiation Resistant, High Temperature Kapton KAP301 wires
With the new KAP301 wires, Allectra offers special radiation resistant Kapton insulated wires.
The quality of these KAP301 cables is improved and this quality will replace the 311-KAPM-RAD versions.
KAP301 wires are available the following sizes:
- Multistrand wire, 0.35mm diameter 301-KAPM-035
- Multistrand wire, 0.6 mm diameter 301-KAPM-060
Other sizes will follow soon, including thermocouple wires.
These cables are offered on spools with 5m...
New Biallec’s 2018 catalogue, specialist for UHV connections
The New Biallec's 2018 catalogue is available. Several series of our products are based on patented technologies, will grant unique properties and expand the capabilities of their products
The connection of pipes is an essential step in the industry. Currently offers a range of electrically isolated flanges for UHV (ultra high vacuum) conditions.
This system, known as FLOVAC, is much more compact...
